EM114053-01
Multi-measurement: kWh, W, V, A, PF, Hz, etc.
Prepaid function
4G communication
external SIM card slot
Built-in relay
LCD Display
Din Rail Mounted
1P2W
EM114053-01 is a single phase prepayment DIN rail 4G electricity meter with built-in latching relay, GPRS-4G comm. and external SIM card slot. It supports connecting to internet when power on, remote reading setting, remote switching off, etc.It is applicable to smart home, smart school and smart industrial energy management system.
| Specification | Voltage | 220V |
| Current | 5(60)A | |
| Impulse Constant | 1600imp/kWh | |
| LCD Display | LCD5+1 | |
| Temp. Range | -20～70℃ | |
| Annual Average Humidity | 75% | |
| Maximum Humidity | 95% | |
| Frequency | 50Hz | |
| Accuracy Class | Cl.1.0 | |
| Starting Current | 0.4%Ib | |
| Power Consumption | <2W / <10VA @Un | |
| Low Balance Indicator | Green LED Flashes | |
| Abnormal Network Indicator | The triangle logo flashes on the LCD | |
| Other Protection | Over-load protection, tamper Protection | |
| Module | CAT 1 | |
| Frequency Band | LTE-TDD:B34/B38/B39/B40/B41,LTE-FDD:B1/B3/B5/B8 |
