8V~48V Din Rail Low Voltage DC Energy Meter with RS485 Modbus Communication

EM613005

Multi-measurement: kWh, V, I, etc.

4 tariffs and 8 slots

RS485 DLT645 Communication

Event log

LCD Backlight Display

Alarm function

DC8V-48V

Inquire Now Next Product

Product Description

EM613005 is a DC DIN rail energy meter which can measure 10~240A, 8~48VDC. With shunt sampling, the accuracy is excellent, it can measure DC energy, current, voltage etc. It also supports 4 tariffs and 8 slots, over/under-voltage alarm, over current alarm, event log, LCD display, FW upgrade, RS485 communication and DLT645 & Modbus protocol. this meter can be applied to New Energy Area, like Solar System and EV Charger (Electric Car).

Din Rail DC Energy Meter Series
Models	EM613001	EM613005	EM619001	EM619002
Measurement Mode	Absolute Value		Bi-directional Active Measurement
External Power Supply	DC 40V~400V	DC 8V~48V	AC/DC 85~265V	DC 9~60V
Voltage	DC 40V~400V	DC 8V~48V	DC 5V~1000V
Current	10A~240A		Up to 2000A（Integrated Meter Signal: 75mV）
Accuracy Class	Cl.1.0
Pulse Constant	100imp/kwh	1000imp/kwh
LCD Display	LCD Backlit 6+2
Alarming	Over or Under-voltage,Over-current Alarm, Threshold Value Can Be Set
Overcurrent Disconnect	/		Single Channel Auxiliary Relay for Overcurrent Cut-off Signal Output (Need External Relay to Cut-off)
Communication	RS485
Commmunication Protocol	DLT645 Protocol	DLT645/Modbus Protocol	DLT645/Modbus Protocol
Communication Speed	9600 bps	9600 bps	Max 115200 bps
Multi-tariff	Yes
Power Consumption	≤8VA ≤0.4W
Ambient Temperature	-25~+70℃ -25～+70℃
Ambient Humidity	≤95%
Installation	Standard Din Rail
Shunt	Built-in		Not Included, Need External Shunt for Current Sampling
Typical Application	This Series of DC Din Rail Type Energy Meters are Widely Used in Photovoltaic Power Generation, Energy Storage Battery Systems, Electric Vehicle Charging Piles, Communication Base Stations, Computer Rooms and Other fields.
