32A 63A 75A 100A MID Single Phase RS485 Modbus Bi-directional Energy Meter for EV Charging Metering

Share

EM118090

Multi-measurement: kWh, W, V, I, PF, Hz, etc.

Bi-directional metering

MID & CE-LVD, CE-EMC Certified

RS485 Communication

Max. 100A Direct Load

1 Module 18mm Width

LCD backlight display

1 Phase 2 wire


Product Description

32A 63A 75A 100A MID Single Phase RS485 Modbus Bi-directional Energy Meter for EV Charging Metering

The EM118090 is a single-phase DIN Rail energy meter that supports bidirectional metering, can read the meter data in real time via RS485 communication, and is only 18mm wide, four Measurement mode can be switched, and has obtained MID,LVD,EMC certification, suitable for domestic or commercial distribution systems, as well as new energy metering systems, such as EV charging stations and solar power generation systems.



TypeEM118089EM118090EM118091
Electrical Parameters
Measurement
Voltage, Current, Active Power, Reactive Power, Apparent Power, Frequency, Power Factor
Active/Reactive Energy And Forward And Reverse Measurement (Four Quadrant Measurement)
Ref. voltage230V
Ref. current0.25-5(30)A, 5(32)A,5(40)A,5(45)A, 5(50)A, 5(80)A, 5(100)A
Impulse Constant1000imp/kWh1000imp/kWh1000imp/kWh
CommunicationN/ARS485 Modbus/DLT645RS485 Modbus/DLT645
Baud rateN/A9600\19200\38400\1152009600\19200\38400\115200
SO outputYes,SO1 for Active :
with variable constant
100-2500imp/kWh
Divisible by 10000
Yes,SO2 for Reactive:
with variable constant
100-2500imp/kvarh
Divisible by 10000
N/AN/A
Li-BatteryN/AN/AYES
Multi-tariffN/AN/AYES
Pulse widthSO:100-1000:100ms
SO:1000-2500:30ms
N/AN/A
BacklightBlueBlueBlue
Measurement Mode1-Total=Forward
2-Total=Reverse
3-Total=Forward+Reverse (default)
4-Total=Forward-Reverse
1-Total=Forward
2-Total=Reverse
3-Total=Forward+Reverse (default)
4-Total=Forward-Reverse
1-Total=Forward
2-Total=Reverse
3-Total=Forward+Reverse (default)
4-Total=Forward-Reverse
ButtonTouch buttonTouch buttonTouch button
Button functionPage turning, setting,
 information display
Page turning, setting,
 information display
Page turning, setting,
 information display
Default  setting1000imp/kWh,100ms
1000imp/kvarh,100ms
9600/NONE /8/19600/NONE /8/1
Measurement
 Mode setting
ButtonRS485 or ButtonRS485 or Button
