Single Phase DIN Rail RS485 Modbus Energy Meter Built-in Relay
Single Phase DIN Rail RS485 Modbus Energy Meter Built-in RelaySingle Phase DIN Rail RS485 Modbus Energy Meter Built-in RelaySingle Phase DIN Rail RS485 Modbus Energy Meter Built-in RelaySingle Phase DIN Rail RS485 Modbus Energy Meter Built-in Relay

Single Phase DIN Rail RS485 Modbus Smart Energy Meter With Relay

Share

EM113016-04

Multi-measurement: kWh, W, V, A, PF, Hz, etc.

RS485 Modbus / DLT645 Communication

Built-in latching relay

LED backlight display

Din Rail Mounted

1P2W

Inquire Now Next Product
Product Description

EM113016-04 is a single phase multi-functional DIN Rail meter with relay.It support RS485 communication, remote reading, remote control, automatic switching, din rail installation, light weight, beautiful appearance,Can measure active power, reactive power, voltage, current, power, frequency, power factor, etc.


Specifications Voltage220V
Current5(80)A
Impulse Constant1600imp/kWh
LCD DisplayLCD5+1
Temp. Range-20～70℃
Annual Average Humidity75%
Maximum Humidity95%
Frequency50Hz
Accuracy ClassCl.1.0
Starting Current0.4%Ib=20mA
Power Consumption≤0.4W / ≤8VA @ Un
CommunicationRS485
ProtocolMODBUS,DLT645-1997,DLT645-2007
