Single Phase DIN Rail Wireless WIFI Prepaid Smart Energy Meter for IOT

Share

EM114023-01

Multi-measurement: kWh, W, V, A, PF, Hz, etc.

WIFI Communication

Prepaid function

Built-in Relay

LCD Display

1P2W



Product Description

EM114023-01 is a WiFi wireless Smart energy meter, which is applicable to measuring the power consumption of a home or factory. Users can connect intelligent devices with energy meter through WIFI, read data and control remotely through intelligent devices, visualize LCD display, and measure voltage, current, total power and power in real time. You can clearly understand the power consumption of connected devices and easily manage various devices.


SpecificationVoltage220V
Current5(60)A
Impulse Constant1600imp/kWh
LCD DisplayLCD5+1
Temp. Range-20~70℃
Annual Average Humidity75%
Maximum Humidity95%
Frequency50Hz
Accuracy ClassClass 1
Starting Current0.4%Ib
Power Consumption<2W / <10VA @ Un
Network instructionsGreen light indicator always on:normal network;Green light Indicator one second on & one second off:abnormal network
Reference StandardGB/T17215.321,IEC62055-41
